分离
Separating agent
预铣
Pre-milling
斜面成型
Bevel forming
边带刻槽
Grooving
斜面涂胶
Bevel gluing
烤灯
Hot lamp
上胶炉
Glue pot
快速熔胶
Quick melt adhesive
直边压贴
Straight edge pressing
斜边压贴
Bevelled pressing
斜直同步压贴
Synchronous pressing
粗修
Rough trimming
齐头齐尾
Head to tail alignment
斜边修边
Trim the bevel edge
直边修边
Straight edge trimming
跟踪倒角
Tracking chamfer
斜边刮边
Bevelled edge scraping
直边刮边
Straight edge pressing
清洗
Cleaning
抛光①
Polishing
抛光②
Polishing
| 型号Model：FM468JCD | |||
| 电动升降Electric lift | 电动式 | 进给速度Feed rate | 16-23m/min |
| 直边/斜边板料宽度Straight edge/beveled edge sheet width | ≥60/80mm | 输入电压Input voltage | 380V |
| 直边/斜边板料厚度Straight edge/beveled edge sheet thickness | 9-60mm/15-40mm | 空气气压Air pressure | 0.7mpa |
| 封带厚度Sealing thickness | 0.4-3mm | 总功率Gross power | 24KW |
| 封带宽度Sealing width | 12-65mm | 机器尺寸(长*宽*高) Machine size (L * W * H) |
9900*740*1750mm |
